Check valve for Samozzi VNR-212-1/2 air suspension
• Connection: internal thread G1/2.
• Nominal flow: 5800 Nl/min.
• Minimum operating pressure: 0.02 bar.
• Operating temperature: 0°C ? 80°C.
• Overall size: 58.5 mm.
• External hexagon wrench: 27 mm.
• Design: valve type with spring.
• Mounting: in any position.
• Body material: brass.
• Spring material: stainless steel.
• Seals: NBR.
• Operating medium: filtered air with or without lubricant.< br /> • Valve-type design with a spring allows operation with low pressure differences at the inlet and outlet. Compressed air is passed through the check valve in one direction only.
Manufacturer Italy
